Wind Generator
WFD200W
Introducing WFD200W – A wind generator with beautiful shape, safe, portable and reliable. It is especially designed to meet the demand from individual householders for a renewable energy source.
The WFD200W is used to charge 12V or 24V batteries. Equipped with suitable DC to AC inverter, it is capable of supplying power for:
Refrigeration
Electric fan
Lights
Navigational equipment
Communication equipment
Features :
Reliable passive self furling
Autobrake slows down the blades spin when the batteries are charged
Marine quality powder coated aluminum body, all stainless steel hardware, water tight housing
Reliability: The design of the body efficiently flows excess heat into the wind reducing operating temperature
One year warranty; operational life expected to be in excess of 15 years.
Wiring :
Specification
| Model |
WFD200W |
| Rated Power |
200W |
| Max Power |
300W |
| OUTPUT DC VOLTAGE |
12V or 24V |
| Start Wind Speed |
2.5 m/s |
| Rated Wind Speed |
9 m/s |
| SURVIVAL WIND SPEED |
40 m/s |
| Cut-Out Wind Speed |
12 m /s |
| Over speed Protection |
Auto Furl |
| Gearbox |
None, Direct Drive |
| Temperature Range |
-40 to +60 Deg. C |
| ROTOR Diameter |
1.7 m |
| Rotor speed |
530rpm |
| Blade material |
Aluminum Alloy |
| Height of tower |
4.5m |
| Generator |
3 phase permanent magnet alternator |
| Sine Inverter power output |
AC 110/220V, 50HZ/60HZ |
| Turbine Weight(kg) |
11 |
